XC95216-10PQ160C

XC95216-10PQ160C, Programmable CPLD, QFP, -0.5 to 7.0V, 24mA, Xilinx, Inc

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: XC95216-10PQ160C

Brand:: Xilinx, Inc - Xilinx | Pack: QFP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Edward's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-12-11

From Other Seller

Part Number:XC95216-10PQ160C
US $1.00 - 2.00
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
YL-G709

US $65.00 - 68.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The XC95216-10PQ160C is a Programmable CPLD. The XC95216-10PQ160C is a high-performance CPLD providing advanced in-system programming and test capabilities for general purpose logic integration. The XC95216-10PQ160C is comprised of twelve 36V18 Function Blocks, providing 4,800 usable gates with propagation delays of 10 ns.

Parametrics

XC95216-10PQ160C absolute maximum ratings: (1)Supply voltage relative to GND : -0.5 to 7.0 V; (2)DC input voltage relative to GND : -0.5 to VCC + 0.5 V; (3)Voltage applied to 3-state output with respect to GND : -0.5 to VCC + 0.5 V; (4)Storage temperature : -65 to +150℃; (5)Max soldering temperature (10 s @1/16 in = 1.5 mm) : +260 ℃.

Features

XC95216-10PQ160C features: (1)10 ns pin-to-pin logic delays on all pins; (2)fCNT to 111 MHz; (3)216 macrocells with 4800 usable gates; (4)Up to 166 user I/O pins; (5)Enhanced pin-locking architecture; (6)Extensive IEEE Std 1149.1 boundary-scan (JTAG) support; (7)Programmable power reduction mode in each macrocell; (8)Slew rate control on individual outputs; (9)User programmable ground pin capability; (10)Extended pattern security features for design protection; (11)High-drive 24 mA outputs; (12)3.3 V or 5 V I/O capability; (13)Advanced CMOS 5V FastFLASH technology; (14)Supports parallel programming of more than one XC9500 concurrently; (15)Available in 160-pin PQFP, 352-pin BGA, and 208-pin HQFP packages.
