MC33972DWBR2

Multiple Switch Detection Interface, suppressed wake-Up, SSOP32

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~1.00

PartNumber:: MC33972DWBR2

Brand:: Freescale Semiconductor, Inc - Freescale | Pack: SSOP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Edward's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-04-21

From Other Seller

Part Number:MC33972DWBR2
US $1.00 - 1.00
IRF3205

US $0.80 - 2.50 / Piece
(0) Remove
AT24C02BN-SH-T

US $0.08 - 0.15 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MC33972DWBR2 Multiple Switch Detection Interface with suppressed wake-Up is designed to detect the closing and opening of up to 22 switch contacts. The switch status, either open or closed, is transferred to the microprocessor unit (MCU) through a serial peripheral interface (SPI). The device also features a 22-to-1 analog multiplexer for reading inputs as analog. The analog input signal is buffered and provided on the AMUX output pin for the MCU to read. The MC33972DWBR2 has two modes of operation, Normal and Sleep. Normal Mode allows programming of the device and supplies switch contacts with pull-up or pull-down current as it monitors switch change of state. The Sleep Mode provides low quiescent current, which makes the MC33972DWBR2 ideal for automotive and industrial products requiring low sleep-state currents.

Parametrics

Electrical ratings: (1)VDD Supply Voltage, CS, SI, SO, SCLK, INT, AMUX: -0.3 to 7.0 VDC; (2)WAKE: -0.3 to 40 VDC; (3)VPWR Supply Voltage: -0.3 to 50 VDC; (4)VPWR Supply Voltage at -40C: -0.3 to 45 VDC; (5)Switch Input Voltage Range: -14 to 40 VDC; (6)Frequency of SPI Operation (VDD = 5.0V): 6.0 MHz; (7)ESD Voltage, VESD: ±2000v at Human Body Model; ±2000v Applies to all non-input pins; ±200v at Machine Model; 750 v at Charge Device Model Corner Pins; 500 v at Charge Device Model Interior Pins.

Features

Features: (1)Designed to operate 5.5V ≤ VPWR ≤ 26V; (2)Switch input voltage range -14V to VPWR, 40V Max; (3)Interfaces directly to MPU using 3.3V/5.0V SPI protocol; (4)Selectable wake-up on change of state; (5)Selectable wetting current (16mA or 2.0mA); (6)8 programmable inputs (switches to battery or ground); (7)14 switch-to-ground inputs; (8)Typical standby current - VPWR = 100μA and VDD = 20μA; (9)Active interrupt (INT) on change-of-switch state; (10)Pb-free packaging designated by suffix code EW; (11)Exposed pad packaging designated by suffix code EK.
