Product Summary
The LM2937IMP-5.0 is a positive voltage regulator capable of supplying up to 500 mA of load current. The use of a PNP power transistor provides a low dropout voltage characteristic. With a load current of 500 mA the minimum input to output voltage differential required for the output to remain in regulation is typically 0.5V (1V guaranteed maximum over the full operating temperature range). The LM2937IMP-5.0 requires an output bypass capacitor for stability. It is stable for all ESR below 3W. This allows the use of low ESR chip capacitors.
Parametrics
Absolute maximum ratings: (1)Input Voltage Continuous: 26V; (2)Transient (t ≤100 ms): 60V; (3)Internal Power Dissipation: Internally Limited; (4)Maximum Junction Temperature: 150℃; (5)Storage Temperature Range: -65℃ to +150℃; (6)SOT-223 (Vapor Phase, 60 seconds): 215℃; (7)SOT-223 (Infared, 15 seconds): 220℃; (8)ESD Susceptibility: 2 kV.
Features
Features: (1)Fully specified for operatioover -40℃ to +125℃; (2)Output current iexcess of 500 mA; (3)Output trimmed for 5% tolerance under all operating conditions; (4)Typical dropout voltage of 0.5V at full rated load current; (5)Wide output capacitor ESR range, up to 3W; (6)Internal short circuit and thermal overload protection; (7)Reverse battery protection; (8)60V input transient protection; (9)Mirror image insertioprotection.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LM2937IMP-5.0 |
National Semiconductor (TI) |
Low Dropout (LDO) Regulators |
Data Sheet |
|
|
||||||||||||
 |
LM2937IMP-5.0/NOPB |
National Semiconductor (TI) |
Low Dropout (LDO) Regulators 500 MA LDO REG |
Data Sheet |
|
|
||||||||||||
