Product Summary
The FDS4559-NL is a 60V complementary powertrench MOSFET. This complementary MOSFET device is produced using Fairchilds advanced PowerTrench process that has been especially tailored to minimize the on-state resistance and yet maintain low gate charge for superior switching performance.
Parametrics
Absolute maximum ratings: (1)Drain-Source Voltage, VDSS: 60V(Q1), –60V(Q2); (2)Gate-Source Voltage, VGSS: ±20V; (3)ID Drain Current - Continuous: 4.5A(Q1), –3.5A(Q2); (4)ID Drain Current - Pulsed: 20A(Q1), –20A(Q2); (5)Power Dissipation for Dual Operation, PD: 2W; (6)Power Dissipation for Single Operation, PD: 1.6W; (7)Operating and Storage Junction Temperature Range, TJ, TSTG: -55 to +175℃.
Features
Features: (1)Q1: N-Channel, 4.5A, 60V RDS(on)=55mΩ at VGS=10V; (2)RDS(on)=75mΩ at VGS=4.5V; (3)Q2: P-Channel; (4)–3.5A, –60V RDS(on)=105mΩ at VGS=–10V; (5)RDS(on)=135mΩ at VGS=–4.5V.
Diagrams
 |
