Product Summary

The 2N4416A is a High Frequency Amplifier.

Parametrics

2N4416A absolute maximum ratings: (1) Gate-Source or Gate-Drain Voltage : -35V; (2) Gate Current : 10mA; (3) Storage Temperature Range : -55 to +150℃; (4) Operating Temperature Range : -55 to +135℃; (5) Lead Temperature (Soldering, 10sec) : +300℃; (6) Power Dissipation : 300mW; (7) Derate above 25℃ : 2.7mW/℃.

Features

2N4416A features: (1)Low Noise; (2)Low Feedback Capacitance; (3)Low Output Capacitance; (4)High Transconductance; (5)High Power Gain.

Diagrams

2N4416A Pin configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
2N4416A
2N4416A
Central Semiconductor
JFET N-Chan JFET
Data Sheet
0-1: $2.17
1-25: $2.03
25-100: $1.92
100-250: $1.83
2N4416A-E3
2N4416A-E3
Vishay/Siliconix
JFET 35V 5mA
Data Sheet
0-1: $2.39
1-25: $2.24
25-50: $2.09
50-100: $1.97
